产品展示
| DN | DA | PN0.4MPa | PN0.6MPa | ||||||
| SN5000 | SN10000 | SN5000 | SN10000 | ||||||
| e | kg/m | e | kg/m | e | kg/m | e | kg/m | ||
| 300 | 324 | 6.2 | 11.5 | 7.5 | 14.5 | 6.6 | 12.5 | 7.6 | 14.1 |
| 400 | 427 | 7.8 | 19.4 | 9.3 | 24.1 | 8.3 | 21.0 | 9.5 | 23.9 |
| 500 | 514 | 9.0 | 27.7 | 10.9 | 34.5 | 9.8 | 31.0 | 11.1 | 34.2 |
| 600 | 616 | 10.5 | 39.6 | 12.8 | 49.3 | 11.1 | 41.3 | 13.1 | 48.8 |
| 700 | 718 | 12.2 | 53.7 | 14.9 | 67.0 | 12.8 | 56.0 | 15.1 | 66.0 |
| 800 | 820 | 13.7 | 6935 | 16.6 | 86.2 | 13.9 | 70.5 | 17.1 | 85.7 |
| 900 | 924 | 15.3 | 88.1 | 18.6 | 110.1 | 15.6 | 89.7 | 19.1 | 108.4 |
| 1000 | 1026 | 16.9 | 108.2 | 20.6 | 135.8 | 17.3 | 110.5 | 21.0 | 133.2 |
| 1100 | 1127 | 18.4 | 130.4 | 22.5 | 163.5 | 18.8 | 127.6 | 23.0 | 160.6 |
| 1200 | 1229 | 20.0 | 154.8 | 24.4 | 193.7 | 20.0 | 153.8 | 24.9 | 190.2 |
| 1400 | 1434 | 23.1 | 209.9 | 28.4 | 264.9 | 23.2 | 208.9 | 28.9 | 258.3 |
| 1500 | 1536 | 24.7 | 241.1 | 30.3 | 302.0 | 24.6 | 229.4 | 30.9 | 296.2 |
| 1600 | 1638 | 26.3 | 273.6 | 32.1 | 342.7 | 26.4 | 271.5 | 32.8 | 336.2 |
| 1800 | 1842 | 29.3 | 344.8 | 36.2 | 434.7 | 29.2 | 338.0 | 36.7 | 424.1 |
| 2000 | 2046 | 32.5 | 424.1 | 40.0 | 534.8 | 32.3 | 417.7 | 40.5 | 521.1 |
| 2200* | 2250 | 35.5 | 512.5 | 43.8 | 645.0 | 35.5 | 504.5 | 44.4 | 629.0 |
| 2400* | 2400 | 37.8 | 583.0 | 46.5 | 732.9 | 37.8 | 573.6 | 47.2 | 714.9 |
| DN | DA | PN0.8MPa | PN1.0MPa | PN1.2MPa | PN1.6MPa | PN2.0MPa | PN2.5MPa | ||||||
| SN10000 | SN10000 | SN10000 | SN10000 | SN10000 | SN10000 | ||||||||
| e | kg/m | e | kg/m | e | kg/m | e | kg/m | e | kg/m | e | kg/m | ||
| 300 | 324 | 7.7 | 14.1 | 7.9 | 15.4 | 8.0 | 15.0 | 9.7 | 18.2 | 11.2 | 21.2 | 13.3 | 24.8 |
| 400 | 427 | 9.7 | 23.9 | 10.1 | 26.0 | 10.0 | 25.2 | 12.2 | 30.5 | 13.7 | 34.4 | 16.4 | 40.4 |
| 500 | 514 | 11.4 | 34.3 | 12.1 | 39.1 | 12.0 | 37.8 | 13.2 | 41.1 | 15.8 | 49.7 | 18.7 | 57.7 |
| 600 | 616 | 13.3 | 48.8 | 13.8 | 52.1 | 13.7 | 50.6 | 14.5 | 53.7 | 18.1 | 68.3 | 21.2 | 75.9 |
| 700 | 718 | 15.5 | 65.9 | 15.6 | 69.1 | 15.8 | 68.2 | 16.2 | 70.6 | 20.7 | 88.7 | 23.9 | 101.6 |
| 800 | 820 | 17.4 | 85.6 | 17.0 | 87.3 | 17.1 | 86.1 | 17.3 | 87.5 | 22.5 | 110.8 | 26.6 | 127.9 |
| 900 | 924 | 19.4 | 108.2 | 19.2 | 111.1 | 19.2 | 108.5 | 21.1 | 116.2 | 25.6 | 142.0 | 31.0 | 169.0 |
| 1000 | 1026 | 21.3 | 132.7 | 21.2 | 136.9 | 21.2 | 133.5 | 23.1 | 141.6 | 28.1 | 173.0 | 33.8 | 204.6 |
| 1100 | 1127 | 23.4 | 160.1 | 23.0 | 158.2 | 22.9 | 153.9 | 24.0 | 159.2 | 29.9 | 197.6 | ||
| 1200 | 1229 | 25.3 | 189.2 | 25.0 | 194.1 | 24.9 | 188.1 | 27.2 | 199.7 | 33.0 | 244.0 | ||
| 1400 | 1434 | 29.3 | 257.1 | 29.1 | 264.2 | 28.9 | 255.3 | 33.9 | 291.9 | 38.0 | 328.4 | ||
| 1500 | 1536 | 31.4 | 295.0 | 30.6 | 289.9 | 30.4 | 280.4 | 35.4 | 318.8 | 39.9 | 360.1 | ||
| 1600 | 1638 | 33.3 | 334.8 | 33.2 | 345.4 | 32.9 | 332.8 | 38.7 | 381.3 | 43.4 | 428.9 | ||
| 1800 | 1842 | 37.3 | 422.3 | 36.7 | 430.5 | 36.3 | 413.8 | 42.9 | 476.0 | ||||
| 2000 | 2046 | 41.2 | 519.2 | 40.9 | 535.0 | 40.3 | 511.0 | ||||||
| 2200* | 2250 | 45.1 | 625.9 | 44.9 | 644.9 | 44.2 | 617.2 | ||||||
| 2400* | 2400 | 47.9 | 711.5 | 47.9 | 733.9 | 47.1 | 701.7 | ||||||
